| Advantages |
* High efficient touch screen seek |
| * Using top quality industrial motherboard |
| * 15-inch TFT LCD Monitor, 1024 x 768,32bit colour |
| * Five line resistance touch screen, the click life can reach 3.5 million times. |
| * Excellent personalized design adapt to any environment |
| * Modular design & convenient maintenance |
| Item |
OA-9000 |
| Mainboard |
Indurstry Motherbaord Intel J1900 |
| Processor |
2.0 GHz |
| Memory |
2 GB |
| Graphical Display |
Integrated Intel GMA3950, Support DirectX9.0 |
| Outer I/O Interface |
RJ-45 LAN Port x 2; PS/2 Keyboard Port x 1 |
| VGA Port x 1; USB2.0 x6 |
| Serial Port x 2; Parallel Port x 1 |
| DC Power Port x 1 |
| Display |
VFD 2 lines customer display / 12 inch Advertising moniter/ MSR |
| Video Memory |
Max Support 224MB Dynamic Video Memory |
| HDD |
32 G SSD / 320 G HDD |
| LCD |
15" TFT LCD |
| Brightness |
250cd/m2 |
| Resolution |
1024x768(max) |
| Touch Screen |
Top quality five line resistance touch screen |
| Visible Angle |
Horizontal: 140, Vertical: 130 |
| Operation Temperature |
0°C to 40°C |
| Storage Temperature |
-20°C to 40°C |
| Packing Size |
40X40X30 cm |
| Net Weight |
5.5 kgs |
| Gross Weight |
6.5kgs |
| Power |
DC 12V Outer Adapter Input |
Note : This type with 80 mm printer , cash drawer optional
Color optional
OEM support
