| Advantages |
* High efficient touch screen seek |
| * Using top quality industrial motherboard |
| * 15-inch Touch TFT LCD Monitor, 1024 x 768,32bit colour |
| * 7 " LCD high resolution advertising moniter |
| * Five line resistance touch screen, the click life can reach 3.5 million times. |
| * Excellent personalized design adapt to any environment |
| * Modular design & convenient maintenance |
| Item |
OA-900A |
| Mainboard |
Top Grade Industrial Mainboard Intel J1800 |
| Processor |
2.0GHz |
| Memory |
2 GB or 4 GB |
| Graphical Display |
Integrated Intel GMA3550, Support DirectX9.0 |
| Outer I/O Interface |
RJ-45 LAN Port x 2; PS/2 Keyboard Port x 1 |
| VGA Port x 1; USB2.0 x 4 |
| Serial Port x 4; Parallel Port x 1 |
| DC Power Port x 1 |
| Optional |
VIP Card Reader, 2 Tracks |
| Video Memory |
Max Support 224MB Dynamic Video Memory |
| Storage |
32 G ssd or hither or 320 G HDD |
| LCD |
15 " TFT LCD |
| Brightness |
250cd/m2 |
| Resolution |
1024x768(max) |
| Touch Screen |
15 " touch screen Top quality five line resistance touch screen |
| OS |
windows or Android |
| Visible Angle |
Horizontal: 140, Vertical: 130 |
| Operation Temperature |
0°C to 40°C |
| Storage Temperature |
-20°C to 40°C |
| Power |
DC 12V Outer Adapter Input |
With 58 mm thermal printer , lcd customer display, 7 inch second moniter optional
OEM support
